Liquid Penetrant - Consumables

Fluorescent Penetrant Sherwin

A full range of consumables compliant with most of aerospace industry requirements of AMS 2644.
Most of the products are approved or meet the following specifications or standards:

Airbus
Alcoa
Allison ASME Code Section V
ASTM E-1417/ASTM-E165 Augusta
Boeing
British Aerospace
CFMI
Dassault
EADS
PMCU

Embraer ISO 3452
Fiat Aviazione
Garret
GE
MTU
RCCM
Rolls Royce
Safran
Turbomeca

Fluorescent Penetrants	Sensitivity Level	Characteristics	Packaging
Water washable, method A	1, 2 and 3	Excellent washability; reduced background; excellent electrostatic spray capability: Rapid gelification	Spray can: 1L, 5L, 10L, 25L, 60L and 200L
Water washable, method A Bio degradable	3 and 4	Do not contain petroleum distillates; resistance to overwashing	Spray can: 1L, 5L, 10L, 25L, 60L and 200L
Post-emulsifiable, Method B, C and D	1, 2, 3 and 4	Very good resistance to over washing with ER83 emulsifier; low background and good contrast	Spray can: 1L, 5L, 10L, 25L, 60L and 200L
Water-based/Surfactant based, Method A	1, 2 and 3	Biodegradable; resistance to over – washing; no flash point	1L, 5L, 10L, 60L and 200L
Bio degradable, Method A	1, 2 and 3	Excellent washability; reduced background; high flash point	Spray can: 1L, 5L, 10L, 25L, 60L and 200L

Emulsifiers	Characteristics	Packaging
Hydrophilic, method D	Qualified for concentrations up to 30%	Spray can: 300ml 5%; 1L, 5L, 10L, 60L and 200L

Cleaners/Removers	Characteristics	Packaging
Class 2	Excellent solvent action for both pre-cleaner and remover	Spray can: 1L, 5L, 10L, 25L, 60L, and 200L

Developers	Characteristics	Packaging
Form a, b, c, d and e	Excellent solvent action for both pre-cleaner and remover	Spray can: 1L, 5L, 10L, 25L, 60L, and 200L

Visible dye Penetrants SREM Technologies

A full range of consumables compliant with most of aerospace and industry requirements :

AMS 2644
ISO 3452-2
ASME
PMUC
RCC-M

Visible Dye Penetrants	Sensitivity Level	Characteristics	Packaging
Method A and C	2	Excellent washability; reduced background; excellent electrostatic spray capability: Rapid gelification	Spray can: 1L, 5L, 10L, 25L, 60L and 200L

High Temperature Products	Code Standards	Characteristics	Packaging
Cleaner	ASME, RCCM, RSE-M and PMUC ISO 9934-2	High temperature penetrant remover for hot parts (120ºC to 200ºC)	Spray can: 1L, 5L and 10L
Red dye Penetrant	ASME, RCCM ISO 3452-2 and 3452-5 PMUC	High temperature penetrant can be used up to 200ºC, for welding during pre and post heating	Spray can: 1L, 5L and 10L
Developer	ASME; RCCM PMUC	High temperature developer whose drying time is adapted for parts from 120ºC to 200ºC	Spray can: 1L, 5L and 10L

Low Temperature Products	Code Standards	Characteristics	Packaging
Red dye penetrant	ISO 3452	Low temperature penetrant	Spray can: 1L, 5L and 10L
Developer Form e and d	AMS 2644, ASME and ISO 3452-2	White powder in suspension in an organic medium	Spray can: 1L, 5L and 10L

Water Treatment	Code Standards	Characteristics	Packaging
Additives		Make post-emulsifiable penetrant easier to be absorbed by active carbon	5L and 10L
Active Carbon	REACh and Food Chemicals Codex	Recommended for treatment of water-based effluents, originated by pre-emulsified penetrants.
Floculant		To be used on water polluted by organic products like penetrants. Reduces significantly the consumption of active carbon. Stabilizes the pollutants mud which may be considered as class 1. (domestic pollutants)	25kg bags
Bactericid	REACh	Prevents anaerobic bacteria from developing in the penetrant testing pollutant treatment facilities.	5 and 10L
